5. PARAMETERS
5 - 40
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PB45
CNHF
Command
notch filter
Set the command notch filter.
_ _ x x
Command notch filter setting frequency selection
Refer to table 5.6 for the relation of setting values to frequency.
00h
_ x _ _
Notch depth selection
Refer to table 5.7 for details.
0h
x _ _ _
For manufacturer setting
0h
Table 5.6 Command notch filter setting frequency selection
Setting
value
Frequency [Hz]
Setting
value
Frequency [Hz]
Setting
value
Frequency [Hz]
_ _ 0 0
Disabled
_ _ 2 0
70
_ _ 4 0
17.6
_ _ 0 1
2250
_ _ 2 1
66
_ _ 4 1
16.5
_ _ 0 2
1125
_ _ 2 2
62
_ _ 4 2
15.6
_ _ 0 3
750
_ _ 2 3
59
_ _ 4 3
14.8
_ _ 0 4
562
_ _ 2 4
56
_ _ 4 4
14.1
_ _ 0 5
450
_ _ 2 5
53
_ _ 4 5
13.4
_ _ 0 6
375
_ _ 2 6
51
_ _ 4 6
12.8
_ _ 0 7
321
_ _ 2 7
48
_ _ 4 7
12.2
_ _ 0 8
281
_ _ 2 8
46
_ _ 4 8
11.7
_ _ 0 9
250
_ _ 2 9
45
_ _ 4 9
11.3
_ _ 0 A
225
_ _ 2 A
43
_ _ 4 A
10.8
_ _ 0 B
204
_ _ 2 B
41
_ _ 4 B
10.4
_ _ 0 C
187
_ _ 2 C
40
_ _ 4 C
10
_ _ 0 D
173
_ _ 2 D
38
_ _ 4 D
9.7
_ _ 0 E
160
_ _ 2 E
37
_ _ 4 E
9.4
_ _ 0 F
150
_ _ 2 F
36
_ _ 4 F
9.1
_ _ 1 0
140
_ _ 3 0
35.2
_ _ 5 0
8.8
_ _ 1 1
132
_ _ 3 1
33.1
_ _ 5 1
8.3
_ _ 1 2
125
_ _ 3 2
31.3
_ _ 5 2
7.8
_ _ 1 3
118
_ _ 3 3
29.6
_ _ 5 3
7.4
_ _ 1 4
112
_ _ 3 4
28.1
_ _ 5 4
7.0
_ _ 1 5
107
_ _ 3 5
26.8
_ _ 5 5
6.7
_ _ 1 6
102
_ _ 3 6
25.6
_ _ 5 6
6.4
_ _ 1 7
97
_ _ 3 7
24.5
_ _ 5 7
6.1
_ _ 1 8
93
_ _ 3 8
23.4
_ _ 5 8
5.9
_ _ 1 9
90
_ _ 3 9
22.5
_ _ 5 9
5.6
_ _ 1 A
86
_ _ 3 A
21.6
_ _ 5 A
5.4
_ _ 1 B
83
_ _ 3 B
20.8
_ _ 5 B
5.2
_ _ 1 C
80
_ _ 3 C
20.1
_ _ 5 C
5.0
_ _ 1 D
77
_ _ 3 D
19.4
_ _ 5 D
4.9
_ _ 1 E
75
_ _ 3 E
18.8
_ _ 5 E
4.7
_ _ 1 F
72
_ _ 3 F
18.2
_ _ 5 F
4.5
Table 5.7 Notch depth selection
Setting
value
Depth [dB]
Setting
value
Depth [dB]
_ 0 _ _
-40.0
_ 8 _ _
-6.0
_ 1 _ _
-24.1
_ 9 _ _
-5.0
_ 2 _ _
-18.1
_ A _ _
-4.1
_ 3 _ _
-14.5
_ B _ _
-3.3
_ 4 _ _
-12.0
_ C _ _
-2.5
_ 5 _ _
-10.1
_ D _ _
-1.8
_ 6 _ _
-8.5
_ E _ _
-1.2
_ 7 _ _
-7.2
_ F _ _
-0.6
