5. PARAMETERS
5 - 41
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PB46
NH3
Machine
resonance
suppression
filter 3
Set the notch frequency of the machine resonance suppression filter 3.
To enable the setting value, set "Machine resonance suppression filter 3 selection"
to "Enabled (_ _ _ 1)" in [Pr. PB47].
Setting range: 10 to 4500
4500
[Hz]
PB47
NHQ3
Notch shape
selection 3
Set forms of the machine resonance suppression filter 3.
_ _ _ x
Machine resonance suppression filter 3 selection
0: Disabled
1: Enabled
0h
_ _ x _
Notch depth selection
0: -40 dB
1: -14 dB
2: -8 dB
3: -4 dB
0h
_ x _ _
Notch width selection
0: α = 2
1: α = 3
2: α = 4
3: α = 5
0h
x _ _ _
For manufacturer setting
0h
PB48
NH4
Machine
resonance
suppression
filter 4
Set the notch frequency of the machine resonance suppression filter 4.
To enable the setting value, set "Machine resonance suppression filter 4 selection"
to "Enabled (_ _ _ 1)" in [Pr. PB49].
Setting range: 10 to 4500
4500
[Hz]
PB49
NHQ4
Notch shape
selection 4
Set forms of the machine resonance suppression filter 4.
_ _ _ x
Machine resonance suppression filter 4 selection
0: Disabled
1: Enabled
When "Enabled" is set, [Pr. PB17 Shaft resonance suppression filter] is not
available.
0h
_ _ x _
Notch depth selection
0: -40 dB
1: -14 dB
2: -8 dB
3: -4 dB
0h
_ x _ _
Notch width selection
0: α = 2
1: α = 3
2: α = 4
3: α = 5
0h
x _ _ _
For manufacturer setting
0h
PB50
NH5
Machine
resonance
suppression
filter 5
Set the notch frequency of the machine resonance suppression filter 5.
To enable the setting value, set "Machine resonance suppression filter 5 selection"
to "Enabled (_ _ _ 1)" in [Pr. PB51].
Setting range: 10 to 4500
4500
[Hz]
