18．EtherCAT COMMUNICATION

(5) Manufacturer Hardware Version (1009h)

Index

Sub

Name

Data Type

Access

PDO Mapping

1009h

Manufacturer Hardware Version

VISIBLE STRING

Impossible

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

1009h

Impossible

The hardware version of the EtherCAT network card is returned. Refer to Manufacturer Hardware

Version 2 (2D31h) for the hardware version of the driver.

(6) Manufacturer Software Version (100Ah)

Index

Sub

Name

Data Type

Access

PDO Mapping

100Ah

Manufacturer Software Version

VISIBLE STRING

Impossible

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

100Ah

Impossible

The software version of the EtherCAT network card is returned. Refer to Manufacturer Software Version

2 (2D32h) for the software version of the driver.
