(35) One-touch tuning mode (2D50h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2D50h
0
One-touch tuning mode
UNSIGNED8
rw
Impossible
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2D50h
0
00h to 03h
Impossible
Setting a value of "1" to "3" starts one-touch tuning. After one-touch tuning is completed, the setting
value automatically changes to "0". The description of the setting values is as follows.
This object is available with drivers
Setting
value
Description
0
During one-touch tuning stop
1
Basic mode
2
High mode
3
Low mode
(36) One-touch tuning status (2D51h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2D51h
0
One-touch tuning status
INTEGER8
ro
Impossible
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2D51h
0
00h to 64h
%
Impossible
The one-touch tuning progress is returned.
This object is available with drivers
(37) One-touch tuning Stop (2D52h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2D52h
0
One-touch tuning Stop
UNSIGNED16
wo
Impossible
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2D52h
0
0000h/1EA5h
Impossible
Writing "1EA5h" can stop one-touch tuning. Writing any value other than "1EA5h" causes SDO Abort
Code (0609 0030h Value range of parameter exceeded).
This object is available with drivers
