Xerox Phaser 4510 Service Manual

A-6 Phaser 4500/4510 Service Manual
Appendix
Service Code Table
Service codes that appear in the Phaser 4510’s Service Usage Profile at line
237 and line 262, on the Printer Status page, and are output by the Diagnostic
Fault History utility are defined in the following table. Refer to the Error
Message Summary tables in “Troubleshooting Procedures for Error Messages
and Codes” on page 3-21 for additional information.
Phaser 4510 Service Codes
Code
Error Description
65 Top Cover Open
66 Rear Cover Open
67 Duplex Unit Cover Open
68 Stacker Cover Open
1 E2_01
2 E2_02
3 E2_03
4 E2_04
5 E2_11
6 E2_12
7 E2_13
8 E2_14
9E3_1
10 E3_2
11 E4_0
12 E4_2
13 E4_3
14 E6_1
15 E6_2
16 E7_0
17 E7_1
18 E7_2
19 E7_3
20 Error: Insert Tray 1
21 Error: Insert Tray 2
22 Error: Insert Tray 3
23 Error: Insert Tray 4
24 Out of paper: Load Tray 1
25 Out of paper: Load Tray 2
26 Out of paper: Load Tray 3

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
