Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual A-7
Appendix
27 Out of paper: Load Tray 4
28 Error: Load Tray 1 - wrong size
29 Error: Load Tray 2 - wrong size
30 Error: Load Tray 3 - wrong size
31 Error: Load Tray 4 - wrong size
32 Paper not available: Load Tray 1
33 Paper not available: Load Tray 2
34 Paper not available: Load Tray 3
35 Paper not available: Load Tray 4
36 ODM requesting media
37 Error: Standard Output Bin Full
38 Error: Offset Stacker Full
39 Error: Toner Empty
40 Error: Toner Empty (PP)
41 Error: Install or Reseat Toner Cartridge
42 Error: Install or Reseat Toner Cartridge (PP)
43 Error: Non Xerox Toner Cartridge - Do Not Use
44 Error: Non Xerox Toner Cartridge - Do Not Use (PP)
45 Error: Incorrect Toner Cartridge
46 Error: Incorrect Toner Cartridge (PP)
47 Force Metered Toner
48 Error: Metered Toner Cartridge
49 Configuration Card Invalid
50 Configuration Card Missing
51 Fatal Failure: Duplex
52 Fatal Failure: Stacker
53 Fatal Failure: Tray 3 Needs POPO
54 Fatal Failure: Tray 3 or 4
55 Fatal Failure: Main Motor
56 Fatal Failure: Laser Unit
57 Fatal Failure: Fuser
58 Fatal Failure: Fan
59 Fatal Failure: NVM
60 Fatal Failure: Hard Disk
61 Fatal Failure: Flash DIMM
Phaser 4510 Service Codes
Code
Error Description
