Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-130
FIP 1. 09
016-359 MRAM Fail
Cause:
MRAM Device Error
Solution:
1. Turn the power Off and On to check that the error recurs.
2. Update to the latest F/W.
3. If the problem cannot be solved, replace (REP 5.1 ESS PWB).
FIP 1. 10
016-369 UI Panel - ESS Communication Fail
Cause:
Communication Fail with a UI Panel and ESS F/W.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
• Check the installation of the WIRELESS
ADAPTER
• Is the Connector between the WIRELESS
ADAPTER and the ESS PWB free of broken/bent
pins, foreign substances, burns, and etc., and is
the unit installed properly?
Go to Step 2.
Reinstall the
WIRELESS
ADAPTER
2
• Replace the WIRELESS ADAPTER.
• Does an error occur?
Replace
(REP 5.1 ESS
PWB)
Troubleshooting
complete.
