Xerox WorkCentre 3615 Service Manual

Service Parts Disassembly
Phaser 3610, WorkCentre 3615 Service Manual4-2
Overview
This chapter contains the removal procedures for field-replaceable parts listed in Chapter 5, Parts List.
In most cases, the replacement procedure is simply the reverse of the removal procedure. If necessary,
additional replacement information is provided.
Standard Orientation of the Printer
When needed, printer orientation is called out in the procedure as an aid to locating parts. Illustrated
below are the right, left, front, and rear sides of the printer.
s3610-184
Front
Right
Left
Rear

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
