Xerox WorkCentre 3615 Service Manual

Maintenance
Phaser 3610, WorkCentre 3615 Service Manual6-18
Tag Matrix
Change Tag Introduction
This section describes all of the tags associated with the machine, as well as multinational applicability,
classification codes, and permanent or temporary modification information.
Important modifications to the copier are identified by a tag number which is recorded on a tag
matrix. The tag matrix is on the inside of the Front Cover Assembly.
The Tag information may include:
•Tag
•Class
•Use
• Manufacturing Serial Number
•Purpose
•Name
•Kit Number
•PL Reference.
Classification Codes
A tag number may be required to identify differences between parts that cannot be interchanged, or
differences in diagnostic, repair, installation, or adjustment procedures.
A tag number may also be required to identify the presence of optional hardware, special non-volatile
memory programming, or whether mandatory modifications have been installed. Each tag number is
given a classification code to identify the type of change that the tag has made. The classification
codes and their descriptions are listed in Table 1.
There are no TAGs currently issued for this machine.
Tab le 1 Cl ass if icat io n Cod es
Classification Code Description
USCO Code XE Code
1 Safety
M2 Mandatory tag.
R3Repair tag.
O4 Optional tag.
S4Situational tag
N5 Tag not installed in the field.
6 Refurbishing Only

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
