Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-44
Status Code List (3615)
Note: Be aware that the error code that shows up on the UI for some errors does not have the
same chain link code that will be displayed in the Error History report.
Note: When the LCD Message column displays ‘-’, ’xxxxxxxx’, the LCD doesn’t display any
messages (it displays only the Status code), the error is dealt with internally. When the LCD
Message column displays ’xxxxxxxx Duplicate IPv6 Add….’, the LCD doesn’t display any
messages (displays only the Status code).
Status
Code
(3615)
LCD Display Name/Description of Error FIP
004-310
Optional Feeder Error 004-310
Reseat Optional Feeder.
Power Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
<IOT Option Feeder I/F Failure>
Cause:
The Option Feeder communication
failure is detected.
FIP 1. 01
005-110
Paper Jam 005-110
Open the Document Feeder
Cover and remove paper.
(After jam recovery)
Reload the original that was
removed from the Document
Feeder and press the Start but-
ton.
N Scanned
<PICK UP JAM>
Cause:
Detect PICK UP JAM.
FIP 1. 02
005-112
Paper Jam 005-112
Open the Document Feeder
Cover and remove paper.
(After jam recovery)
Reload the original that was
removed from the Document
Feeder and press the Start but-
ton.
N Scanned.
<REVERSE JAM>
Cause:
Detect REVERSE JAM.
FIP 1. 02

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
