Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-256
FIP 1. 269
061-370 IOT ROS Failure
Cause:
The operation error of ROS (rotational error etc.) is detected.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
Check the connections between the ROS
ASSEMBLY and the MCU PWB, as well as
between the ROS ASSEMBLY and the ESS PWB.
Are the ROS-MCU HARNESS (P/J501-
P/J19), ROS ASSEMBLY (P/J18), and the
VIDEO HARNESS (P/J502 - P/J322)
connected securely?
Go to Step 2.
Securely connect
the ROS-MCU
HARNESS, ROS
ASSEMBLY and
the VIDEO HAR-
NESS
2
•Replace (REP 3.1 ROS Assembly).
Does an error occur?
Go to Step 3.
Troubleshooting
complete.
3
•Replace (REP 5.6 MCU PWB).
Does an error occur?
Replace
(
REP 5.1 ESS PWB)
Troubleshooting
complete.
