Xerox WorkCentre 3615 Service Manual

Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-52
6. Controller (3615)
MCU PWB
PL 5.3
To AC
Power
ESS Harness
PL 5.4
ESS Power Harness
PL 5.4
Speaker
PL5.2
B
From
AC Power
(+24VDC)
F
From
AC Power
(STBY+5VDC)
E
LVPS
PL 5.2
P/J20 P/J421
6
7
8
3
4
1
2
5
7
6
5
10
9
12
11
8
SG
LINE SYNC
SG
PAGE SYNC
SG
TEST PRINT
CMD READY
COMMAND
10
11
12
9
3
2
1
4
STATUS
SG
RDY PWR ON
IOT PWR STS
P/J211 P/J441
3
4
1
2
3
4
1
2
+5VDC
STBY
RTN
+24VDC
RTN
ESS PWB
PL 5.1
STBY
+5VDC
+5VDC
TO
+3.3VDC
+3.3VDC
+24VDC
1
2
SPEAKER OUT
RTN
Wireless Adapter
(Option)
PL5.2
SD-Card (Option)
PL 5.2
P/J412
P/J221
FAX PWB
PL 5.2
P/J4O2
P/J415
P/J432
P/J416
P/J411
P/J414
USB Port
Ethernet Port
MJ2
MJ1
Phone Connector
Wall Jack Connector
MFP Console
PL 1.5
Front USB PWB
PL 5.2
Front
USB Port
s3610-229

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
