Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-329
FIP 2.16
Dispanse Motor
Cause:
Parts to be considered:
• DISPENSE DRIVE ASSEMBLY (PL 3.1 Xerographics)
•DISPENSE MOTOR (PL 3.1 Xerographics)
• DISPENSE MOTOR HARNESS ASSEMBLY(PL 5.4 Electrical Connections)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the DIS-
PENSE MOTOR Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Is the DRIVE ASSEMBLY DISP damaged?
Replace (REP 4.6
Dispense Drive
Assembly)
Go to Step 3.
3
Check the connection between the MOTOR
DISP and the MCU PWB.
• Is the DISPENSE MOTOR HARNESS
ASSEMBLY (P/J111 - P/J11) connected
securely?
Go to Step 4.
Securely
connect the
DISPENSE MOTOR
HARNESS
ASSEMBLY
4
•Replace (REP 4.7 Toner Dispense Motor)
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
• Replace the DISPENSE MOTOR
HARNESS ASSEMBLY.
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
