Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-6
Plug/Jack Locations for Tray 1 and the Optional Feeders
P/J Illustration Description
243 Illustration 06 Connects DRAWER 1 HARNESS ASSY FDR and FDR HARNESS ASSY
419 Illustration 06 Connects OPT TRAY ASSY PWB and FDR DRAWER 1 HARNESS ASSY
420 Illustration 06 Connects OPT TRAY ASSY PWB and C2 TURN HARNESS ASSY
421 Illustration 06 Connects OPT TRAY ASSY PWB and C2 SIZE HARNESS ASSY
422 Illustration 06 Connects OPT TRAY ASSY PWB and TRAY MOTOR HARNES ASSY
423 Illustration 13 Connects OPT TRAY ASSY PWB and DRAWER 2 HARNESS ASSY
4200 Illustration 06 OPT TRAY ASSY PWB (not used)
4201 Illustration 06 Connects OPT FEED CLUTCH ASSY and HARNESS ASSY C2 TURN
4203 Illustration 13 Connects NO PAPER SENSOR and HARNESS ASSY C2 TURN
4212 Illustration 13 Connects PATH SENSOR and HARNESS ASSY
4213 Illustration 13 Connects TAKE AWAY CLUTCH and HARNESS C2 SIZE ASSY
4214 Illustration 13 Connects C2 SIZE HARNESS ASSY and HARNESS ASSY
4221 Illustration 06 Connects MOTOR ASSY and TRAY MOTOR HARNESS ASSY
4231 Illustration 13 Connects DRAWER 2 HARNESS ASSY and DRAWER 1 HARNESS ASSY
