Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-280
FIP 1. 296
093-933 Toner Life Over
Cause:
It was detected that the Toner Cartridge needed to be replaced soon.
Solution:
The Toner Cartridge is approaching the replacement time. Prepare a new Toner Cartridge.
FIP 1. 297
116-210 USB Host Error
Cause:
Fatal error of USB Host driver.
Solution:
1. Turn the power Off and On to check that the error recurs.
2. Update to the latest F/W.
3. If the problem cannot be solved, replace (REP 5.1 ESS PWB).
5
• Check the connection between the
CONNECTOR ASSEMBLY, the CRUM TONER,
and the MCU PWB.
• Is the XEROGRAPHIC CRUM HARNESS
ASSEMBLY(P/J253 - P/J25) connected
securely?
Go to Step 6.
Securely connect
the XERO-
GRAPHIC CRUM
HARNESS ASSEM-
BLY
6
• Replace the TONER CARTRIDGE.
• Does an error occur?
Go to Step 7.
Troubleshooting
complete.
7
•Replace (REP 5.6 MCU PWB)
• Does an error occur?
Go to Step 8.
Troubleshooting
complete.
8
• Replace the XEROGRAPHIC CRUM
HARNESS ASSEMBLY
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
