Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-274
FIP 1. 288
077-312 Tray Configure Error
Cause:
Tray configuration error was detected. (including all of the wrong configurations)
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
• Does the Tray configuration suit the
specification?
Go to Step 2.
Change the Tray
configuration related
to the specification
2
• Check the connections between the OPTIONAL
TRAY PWB ASSEMBLY and the MCU PWB, as
well as between the OPTIONAL TRAY PWB
ASSEMBLY and the LVPS PWB.
• Are the OPTIONAL FEEDER HARNESS
ASSEMBLY (P/J213P/J243, P/J24P/J243) and
the FEEDER HARNESS ASSEMBLY DRAWER 1
(P/J243P/J419) connected securely?
Go to Step 3.
Securely connect
the OPTIONAL
FEEDER HARNESS
ASSEMBLY and the
FEEDER HARNESS
ASSEMBLY
DRAWER 1
3
• Replace the OPTIONAL FEEDER HARNESS
ASSEMBLY.
• Does an error occur?
Go to Step 4.
Troubleshooting
complete.
4
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 1.
• Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
• Check the connection between the OPTIONAL
TRAY PWB ASSEMBLY (Upper) and the
OPTIONAL TRAY PWB ASSEMBLY (Lower).
Are the FEEDER HARNESS ASSEMBLY DRAWER
2 (P/J423 - P/J4231) and the FEEDER
HARNESS ASSEMBLY DRAWER 1 (P/J4231 -
P/J419) connected securely?
Go to Step 6.
Securely connect
the FEEDER HAR-
NESS ASSEMBLY
DRAWER 2 and the
FEEDER HARNESS
ASSEMBLY
DRAWER 1
6
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 2.
• Does an error occur?
Go to Step 7.
Troubleshooting
complete.
7
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 1.
• Does an error occur?
Go to Step 8.
Troubleshooting
complete.
