Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-278
FIP 1. 293
093-426 Toner Near Life
Cause:
It was detected that the Toner Cartridge needed to be replaced soon.
Solution:
The Toner Cartridge is approaching the replacement time. Prepare a new Toner Cartridge.
FIP 1. 294
093-922 Toner Low Density
Cause:
Low concentration of the Toner was detected.
Solution:
1. Remove the Toner Cartridge, shake it a few times, and then reinstall it.
2. If the error persists, ensure that the error is replicated after the printer is powered Off and
then On, and then proceed to the FIP.
6
•Replace (REP 3.3 Xerographic Connector
Assembly).
• Does an error occur?
Go to Step 7.
Troubleshooting
complete.
7
• Replace the XEROGRAPHIC CRUM
HARNESS ASSEMBLY.
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
Step Check and Action Yes No
1
• Remove the TONER CARTRIDGE, shake it
a few times, and then reinstall it.
• Does an error occur?
Go to Step 2.
Troubleshooting
complete.
2
• Remove the DRUM CARTRIDGE.
• Is the contact points of the DRUM
CARTRIDGE clean, and correctly installed?
Go to Step 3.
Clean the contact
points and reinstall
the
DRUM CAR-
TRIDGE
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
