Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-258
FIP 1. 271
062-316 DADF Motor Fail
Cause:
Detect DADF Motor Fail.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
FIP 1. 272
062-790 Copy Limit
Cause:
Copy Limit.
Solution:
The machine will recover after the Enter Key is pressed or message is displayed for 60 seconds.
If the error persists:
1. Change your original.
2. Ensure that the error is replicated after the printer is powered Off and then On, and then
replace (REP 5.1 ESS PWB).
Step Check and Action Yes No
1
Are there any foreign substances in the DADF
Motor Drive Section?
Remove the
foreign sub-
stances.
Go to Step 2.
2
Check the connection between the DADF
ASSEMBLY and the ESS PWB.
• Is the P/J453 connected securely?
Go to Step 3.
Connect P/J453
securely
3
•Replace (REP 6.2 DADF).
• Does an error occur?
Replace
(REP 5.1 ESS
PWB).
Troubleshooting
complete.
