Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-248
FIP 1. 256
042-700 IOT Over Heat Stop
092-661 IOT Environment Sensor Error
Cause:
042-700: The Temp. Sensor sensed high temperature.
092-661: The Temp. Sensor or the Humidity Sensor error was detected.
Solution:
042-700:
• Printing has been suspended because inside of the printer is extraordinarily hot.
• Start the operation after the Printer has cooled down.
• Turn the power Off and On to check that the error recurs. Then proceed to the FIP.
092-661:
Turn the power Off and On to check that the error recurs. Then proceed to the FIP.
Step Check and Action Yes No
1
Is there a heat source near the device?
Remove the heat
source
Go to Step 2.
2
Are there any foreign substances in the Temp.
Sensor /Humidity Sensor HVPS Detector?
Remove the for-
eign substances
Go to Step 3.
3
• Check the connection between the HVPS
and the MCU PWB.
• Is the HVPS HARNESS ASSEMBLY connected
securely?
Go to Step 4.
Securely con-
nect the HVPS
HARNESS
ASSEMBLY
4
• Replace the HVPS HARNESS ASSEMBLY.
• Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
•Replace (REP 5.7 HVPS (3610)) (REP 5.8
HVPS (3615)).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
