Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-326
FIP 2.13
Registration Clutch Assembly
Cause:
Parts to be considered:
• TAKE AWAY ROLL ASSEMBLY (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4))
• REGISTRATION CLUTCH ASSEMBLY (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder
(2/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the
REGISTRATION CLUTCH ASSEMBLY Sec-
tion?
Remove the foreign
substances
Go to Step 2.
2
Is the TAKE AWAY ROLL ASSEMBLY
damaged?
Replace the TAKE
AWAY ROLL ASSEMBLY
Go to Step 3.
3
Check the connection between the
Registration Clutch Assembly and the
MCU.
• Is the harness connected securely?
Go to Step 4.
Securely connect
the harness.
4
• Replace the REGISTRATION
CLUTCH ASSEMBLY.
Does an error occur?
Replace MCU.
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
