Xerox WorkCentre 3615 Service Manual

Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-50
5. Fusing
P/J23 P233 J233
Fuser
PL3.5
LVPS
PL 5.1 / 5.2
MCU PWB
PL 5.3
3
4
1
2
5
6
3
4
1
2
5
6
2
1
5
4
7
7
6
3
SG
STS MAIN
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
SG
STS SIDE
Temperature
Sensor (Main)
Temperature
Sensor (Side)
N.C.
P/J22
P/J27 P/J271
P/J272
P/J250
P/J240 P2401 J2401
P/J251
Test Port
Rear Fan
PL19.2.9
Exit Sensor
PL 2.5
Full Stack Sensor
PL 2.5
P/J220
LVPS Harness
PL 5.4
Fuser Harness
PL 5.4
Test Relay Harness
PL 5.4
Rear Fan Harness
PL 5.4
Exit Sensor Harness
PL 5.4
15
12
16
9
2
5
1
8
HEAT2 (Long)
HEAT1 (Short)
HEATEN
F002
ALM R FAN
P/J201 DP233
DJ233
5
4
3
3
2
1
3
1
2
N HEAT2 (Long)
Heater 2 (Long)
Heater 1 (Short)
Thermostat
N HEAT 1 (Short)
N.C.
N.C.
2
1
LINE
8
7
9
10
R FAN LOW
R FAN STOP
1
8
+3.3VDC
+3.3VDC
2
3
9
10
SG
EXIT SENSOR
4
8
+3.3VDC
5
6
9
10
SG
FULL STACK SENSOR
1
2
3
2
+24V
ALM
3
1
2
3
4
1
RTN
1
2
2
1
On/O
On/O
C
D
From
AC Power
From
AC Power
Relay Control
Rear Fan
Control
s3610-193

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
