Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-331
FIP 2.18
Abnormal Noise: When power is turned on
Cause:
Parts to be considered:
• TONER CARTRIDGE (PL 3.1 Xerographics)
•DISPENSE MOTOR (PL 3.3 Toner Dispense)
•MAIN DRIVE ASSEMBLY (PL 4.1 Drive)
• DRUM CARTRIDGE (PL 3.1 Xerographics)
•FUSING ASSEMBLY (PL 3.5 Fusing Assembly)
• DRIVE EXIT OUT HOLDER ASSEMBLY (PL 4.1 Drive)
• DRIVE EXIT IN HOLDER ASSEMBLY (PL 4.1 Drive)
Solution:
Step Check and Action Yes No
1
• Execute the Diag Digital Output[093-001]
to check the rotation of the DISPENSE
MOTOR.
• Is there any abnormal noise from the
device? Stop the motor operation within
three seconds. If the motor operation is
continued for three seconds or longer, the
device will be damaged.
Go to Step 2. Go to Step 3.
2
• Reinstall the TONER CARTRIDGE.
• Turn the power Off and On.
• Does an abnormal noise occur?
Replace the
TONER
CARTRIDGE
Troubleshooting
complete.
3
• Execute the Diag Digital Output [071-001]
to check the rotation of the MAIN DRIVE
ASSEMBLY.
• Is there any abnormal noise from the
device? Stop the motor operation within
three seconds. If the motor operation is
continued for three seconds or longer, the
device will be damaged.
Go to Step 4.
Troubleshooting
complete.
4
• Replace the DRUM CARTRIDGE.
• Turn the power Off and On.Does an
abnormal noise occur?
Go to Step 5.
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
