Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-314
Level 2 FIPs
FIP 2.01
Exit Sensor
Cause:
Parts to be considered:
•EXIT CHUTE ASSEMBLY (PL 2.5 Exit Chute)
•EXIT SENSOR (PL 2.5 Exit Chute)
• EXIT SENSOR HARNESS ASSEMBLY (PL 5.4 Electrical Connections)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the EXIT
SENSOR Detector?
Remove the for-
eign substances
Go to Step 2.
2 Is the EXIT CHUTE ASSEMBLY damaged?
Replace
(REP 2.11 Exit
Chute Assem-
bly)
Go to Step 3.
3
Check the connection between the EXIT
SENSOR and the MCU PWB.
• Is the EXIT SENSOR HARNESS ASSEMBLY
(P/J271-P/J27) connected securely?
Go to Step 4.
Securely connect
the EXIT SENSOR
HARNESS ASSEM-
BLY
4
• Replace the EXIT SENSOR.
Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
