Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-323
FIP 2.10
Registration Clutch Assembly
Cause:
Parts to be considered:
•MAIN DRIVE ASSEMBLY (PL 4.1 Drive)
• REGISTRATION CLUTCH (REP 5.6 MCU PWB)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the REGI.
CLUTCH Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Is the MAIN DRIVE ASSEMBLY damaged?
Replace
(REP 4.1 Main
Drive Assembly)
Go to Step 3.
3
Check the connection between the REGI.
CLUTCH and the MCU PWB.
• Is the REGI. CLUTCH (P/J12) connected
securely?
Go to Step 4.
Securely con-
nect the REGI.
CLUTCH
4
•Replace (REP 2.6 Registration Clutch)
Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
