Xerox WorkCentre 3615 Service Manual

Specifications
Phaser 3610, WorkCentre 3615 Service Manual 8-3
Functional Configuration
System Configuration for the 3615
IIT (Image Input Terminal):
• The IIT is a device to scan documents for copying, facsimile (FAX) sending, and scanning. The
IIT can scan documents with an optical resolution of 1200 dots/25.4mm and 1200
dots/25.4mm in the fast scan direction. The resolution in the slow scan direction is set based
on the scan speed and electrical resolution conversion.
• The IIT is equipped with the DADF (Duplex Automatic Document Feeder) as standard.
IOT (Image Output Terminal):
• The IOT writes video data from each portion on paper for copying, outputting files received
by the facsimile, and outputting from the printer. The Laser xerography technology engine
allows for image recording on paper up to 14 in. (355.6mm) length at 600 dots/25.4mm.
Operator Panel:
• The operator panel displays various settings, instructions, and error messages for copying,
sending a fax, scanning, and printing. It has touch sensor and buttons for user operations.
The operator panel is also referred to as just “Panel” in this specification.
Engine
Control Panel
2 Line Bitmap LCD Panel
SFP Controller
LM1
Option
࡮
Memory
࡮
SD-Card
ROS
IOT
IOT MCU
Network (Rear)
USB2.0 (Rear)
Wireless Network
(Option)
USB Host 2.0(Rear
）
ZaS06005XB
Option
࡮
550 Sheet Feeder

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
