Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-263
FIP 1. 278
072-102 IOT Option Regi On Jam
Either of the following error codes is displayed in the UI.
•050-137
•050-138
Cause:
After the Tray 2 Path Sensor turned ON, the Regi. Sensor did not turn ON within the specified
time.
Solution:
1. Paper jam has occurred. Remove the jammed paper.
2. If there is no jammed paper, or the error still occurs after having removed the jammed paper,
turn the power Off and On to check that the error recurs, then proceed to the FIP.
6
• Execute the Diag Digital Output Tray 2:
071-009 / Tray 3:071-012 / Tray 4:071-015
to check the rotation of the OPTIONAL
TRAY MOTOR-ASSEMBLY.
• Is it working properly?
Go to Step 7.
Go to
FIP 2.17
7
•Replace (REP 7.8 Feeder Assembly).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
Step Check and Action Yes No
1
Is there any foreign substances or bits of paper
found on the paper transport path?
Remove the for-
eign substances
and bits of paper,
etc.
Go to Step 2.
2
Are the paper feed rolls installed properly?
Go to Step 3.
Reinstall the cor-
responding
paper feed rolls
3
Are the paper feed rolls deformed or worn out?
Replace the corre-
sponding paper
feed rolls
Go to Step 4.
Step Check and Action Yes No
