Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-264
4
• Execute the Diag Digital Input 071-102
to check the operation of the REGI-
SENSOR HVPS.
• Is the REGI-SENSOR HVPS operating
normally?
Go to Step 5.
Go to
FIP 2.03
5
• Execute the Diag Digital Input [071-119]
to check the operation of the Tray 2 Path
Sensor.
• Is the Tray 2 Path Sensor operating
normally?
Go to Step 6.
Go to
FIP 2.07
6
• Execute the Diag Digital Output 071-021
to check the operation of the Tray 2 TAKE
AWAY CLUTCH.
•Is the Tray 2 TAKE AWAY CLUTCH
operating normally?
Go to Step 7.
Go to
FIP 2.13
7
• Check the operation of the OPTIONAL
TRAY MOTOR-ASSEMBLY
• Execute the Diag Digital Output Tray 2:
[071-009] to check the rotation of the
OPTIONAL TRAY MOTOR-ASSEMBLY.
•Is it working properly?
Go to Step 8.
Go to
FIP 2.17
8
•Replace (REP 7.8 Feeder Assembly).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
