Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-319
FIP 2.06
No Paper Sensor
Cause:
Parts to be considered:
• NO PAPER ACTUATOR (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4))
• NO PAPER SENSOR (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4))
• NO PAPER SENSOR HARNESS ASSEMBLY (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder
(2/4))
• C2 TURN HARNESS ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the NO
PAPER SENSOR DETECTOR?
Remove the
foreign substances
Go to Step 2.
2
Is the NO PAPER ACTUATOR damaged?
Replace the NO
PAPER ACTUATOR
Go to Step 3.
3
Check the connection between the No Paper
Sensor and the OPTIONAL TRAY PWB
ASSEMBLY.
• Are the NO PAPER SENSOR HARNESS
ASSEMBLY (P/J4203 - P/J4202) and the
C2 TURN HARNESS ASSEMBLY
(P/J4202 - P/J420) connected securely?
Go to Step 4.
Securely connect
the NO PAPER SEN-
SOR HARNESS
ASSEMBLY and the
C2 TURN HAR-
NESS ASSEMBLY
4
•Replace (REP 7.5 Optional Tray PWB
Assembly).
Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
• Replace the NO PAPER SENSOR
Does an error occur? Go to Step 6.
Troubleshooting
complete.
6
• Replace the C2 TURN HARNESS
ASSEMBLY
• Does an error occur?
Replace (REP 5.6
MCU PWB)
Troubleshooting
complete.
