Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-272
FIP 1. 287
077-304 IOT Cover Rear Open
Cause:
The Rear Cover is open.
Solution:
1. Close the Rear Cover.
2. If the error persists, ensure that the error is replicated after the printer is powered Off and
then On, and then proceed to the FIP.
5
• Replace the Front Interlock Switch.
• Does an error occur?
Replace
(REP 5.6 MCU PWB)
Troubleshooting
complete.
Step Check and Action Yes No
1
• Is the protruding portion of the REAR
COVER ASSEMBLY damaged?
Replace
(
REP 1.5 Rear
Cover Assembly
)
Go to Step 2.
2
• Execute the Diag Digital Output 041-301
to check the operation of the Rear
Interlock Switch.
• Is it working properly?
Replace
(REP 5.6 MCU
PWB)
Go to Step 3.
3
• Check the connection between the Rear
Interlock Switch and the LVPS, as well as
between the LVPS PWB and the MCU
PWB.
• Are the Rear Interlock Switch (P/J230)
and the LVPS HARNESS ASSEMBLY
(P/J220P/J22) connected securely?
Go to Step 4.
Securely connect
the Rear Interlock
Switch
and the LVPS
HARNESS
ASSEMBLY
4
•Replace the
(REP 2.10 Rear Interlock Switch
Assembly).
Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
• Replace the LVPS HARNESS ASSEMBLY.
• Does an error occur?
Go to Step 6.
Troubleshooting
complete.
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
