Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-281
FIP 1. 298
116-312 Encryption Key Error
116-313 Encryption Setting Error
Cause:
116-312: Encryption key mismatch.
116-313: Encryption setting mismatch.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
FIP 1. 299
116-314 MAC Address Error
Cause:
On Board Network MAC Address Checksum Error.
Solution:
1. Turn the power Off and On to check that the error recurs, then replace (REP 5.1 ESS PWB).
Step Check and Action Yes No
1
Is the Connector (P/J221) between the SD CARD
and the ESS PWB free of broken/bent pins, foreign
substances, burns, and etc., and is the unit installed
properly?
Go to Step 2.
Reinstall the SD
CARD
2
• Re-set up the security of the SD CARD.
• Does an error occur?
Go to Step 3.
Troubleshooting
complete.
3
• Replace the SD CARD.
• Does an error occur?
Replace
(
REP 5.1 ESS
PWB
)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
