Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-174
FIP 1. 112
024-910 Tray 1 Paper Size Mismatch
Cause:
The size of paper in the Tray 1does not match the specified print size.
Solution:
1. Open/close Tray, or reseat paper on the manual feed tray.
2. Use the paper that meets the specifications.
3. Make sure that you are using the correct printer driver.
4. Check the Paper Size and Paper Type of the Tray Setting menu on the printer operator panel
and the printer driver.
5. If the problem cannot be solved, replace the corresponding paper feed rolls.
• TRAY 1 FEED ROLL / NUDGER ROLL (PL 2.3 Feed Assembly)
• TRAY 1 RETARD ROLL (PL 7.3 Tray 1/Optional Tray 550-Sheet Feeder (3/4))
• RUBBER ROLL ASSEMBLY (PL 2.2 Transport Assembly)
• REGI PINCHROLL ASSEMBLY (PL 2.2 Transport Assembly)
• REGI PINCH ROLL (PL 2.2 Transport Assembly)
Step Check and Action Yes No
1
Check the connection between the MCU PWB and
the ESS PWB.
• Is the ESS HARNESS ASSEMBLY connected
securely?
Go to Step 2.
Securely connect
the ESS HARNESS
ASSEMBLY
2
• Replace the ESS HARNESS ASSEMBLY.
• Does an error occur?
Go to Step 3.
Troubleshooting
complete.
3
•Replace (REP 5.6 MCU PWB).
• Does an error occur?
Replace
(REP 5.1 ESS
PWB)
Troubleshooting
complete.
