Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-330
FIP 2.17
Optional Tray Motor Assembly
Cause:
Parts to be considered:
•GEAR (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• OPTIONAL FEED GEAR 550 (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4))
•MOTOR-ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• TRAY MOTOR HARNESS ASSEMBLY(PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the
MOTOR ASSEMBLY Drive Section?
Remove the foreign
substances
Go to Step 2.
2
Is the GEAR OPT and the OPTIONAL
FEED GEAR 550 damaged?
Replace the GEAR
and the OPTIONAL
FEED GEAR 550
Go to Step 3.
3
Check the connection between the
MOTOR-ASSEMBLY OPTION and the
PWB ASSEMBLY OPT TRAY.
• Is the TRAY MOTOR HARNESS
ASSEMBLY (P/J4221 - P/J422)
connected securely?
Go to Step 4.
Securely connect
the TRAY MOTOR
HARNESS ASSEM-
BLY
4
•Replace (REP 7.6 Drive Assembly)
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
•Replace the TRAY MOTOR
HARNESS ASSEMBLY
• Does an error occur?
Replace
(REP 5.6 MCU PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
