Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-328
FIP 2.15
Main Drive Assembly
Cause:
Parts to be considered:
•MAIN DRIVE ASSEMBLY (PL 4.1 Drive)
• MAIN MOTOR HARNESS ASSEMBLY (PL 5.4 Electrical Connections)
•LVPS (PL 5.1 Electrical (ESS PWB / LVPS) (3610) / PL 5.2 Electrical (ESS PWB / LVPS)
(3615))
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the MAIN
DRIVE ASSEMBLY Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Is the MAIN DRIVE ASSEMBLY damaged?
Replace
(REP 4.1 Main
Drive Assembly)
Go to Step 3.
3
Check the connections between the MAIN
DRIVE ASSEMBLY and the MCU PWB, as well as
between the MAIN DRIVE ASSEMBLY and the
LVPS PWB.
• Is the MAIN MOTOR HARNESS ASSEMBLY
(P/J101 - P/J10 - P/J101 - P/J212)
connected securely?
Go to Step 4.
Securely connect
the MAIN
MOTOR HAR-
NESS ASSEMBLY
4
•Replace (REP 4.1 Main Drive Assembly)
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
• Replace the MAIN MOTOR HARNESS
ASSEMBLY.
• Does an error occur?
Go to Step 6.
Troubleshooting
complete.
6
•Replace (REP 5.3 LVPS).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
