Service Parts Disassembly
Phaser 3610, WorkCentre 3615 Service Manual4-128
REP 7.8 Feeder Assembly
PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4)
Removal
1. Remove (REP 7.7 Feed Clutch Assembly).
2. Disconnect P/J 4202, 4213 and 4214. (FIgure 1)
Figure 1
s3610-118
P/J4213
P/J4202
P/J4214
To Next Page
