Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-315
FIP 2.02
IOT Standard Stacker Full
Cause:
Parts to be considered:
• FULL STACK SENSOR (PL 2.5 Exit Chute)
• EXIT SENSOR HARNESS ASSEMBLY (PL 5.4 Electrical Connections)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
• Check the connection between the FULL
STACK SENSOR and the MCU PWB.
• Is the EXIT SENSOR HARNESS ASSEMBLY
(P/J272 - P/J27) connected securely?
Go to Step 2.
Securely connect
the EXIT SENSOR
HARNESS ASSEM-
BLY
2
• Replace the EXIT SENSOR HARNESS
ASSEMBLY.
• Does an error occur?
Go to Step 3.
Troubleshooting
complete.
3
•Replace (REP 2.13 Full Stack Sensor).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
