Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-327
FIP 2.14
MSI Feed Solenoid
Cause:
Parts to be considered:
• MSI GEAR SEGMENT 1 (PL 2.6 MSI)
• MSI GEAR SEGMENT 2 (PL 2.6 MSI)
• MSI FEED SOLENOID (PL 2.6 MSI)
•MCU PWB (PL 5.3 Electrical (MCU PWB / HVPS))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the MSI
FEED SOLENOID Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Are the MSI GEAR SEGMENT MSI 1 and the
MSI GEAR SEGMENT 2 damaged?
Replace the
GEAR SEGMENT
1 and the GEAR
SEGMENT 2
Go to Step 3.
3
Check the connection between the MSI FEED
SOLENOID and the MCU PWB.
• Is the MSI FEED SOLENOID (P/J15)
connected securely?
Go to Step 4.
Securely connect
the MSI FEED
SOLENOID
4
•Replace (REP 2.14 MSI Feed Solenoid)
Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
