Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-269
FIP 1. 284
077-106 Exit On Jam
077-108 Exit Off early Jam
077-109 Exit Off Jam
Cause:
077-106:
Either of the following error codes is displayed in the UI.
050-130 - 050-132 - 050-142
The Exit Sensor does not turn ON within the specified time after the Regi Clutch turned
On.
077-108:
050-130 is displayed in the UI.
After the Exit Sensor turned ON, the Exit Sensor turned OFF before the specified time.
077-109:
050-130 is displayed in the UI.
After the Regi. Sensor turned OFF, the Exit Sensor did not turn OFF within the specified
time.
Solution:
1. Paper jam has occurred. Remove the jammed paper.
2. If there is no jammed paper, or the error still occurs after having removed the jammed paper,
turn the power Off and On to check that the error recurs, then proceed to the FIP.
5
• Execute the Diag Digital Output [071-
006] to check the operation of the REGI.
CLUTCH.
• Is the REGI. CLUTCH operating normally?
Go to Step 6.
Go to
FIP 2.10
6
• Execute the Diag Digital Output [071-
001] to check the rotation of the MAIN
DRIVE ASSEMBLY.
•Is it working properly?
Replace
(REP 5.6 MCU PWB)
Go to
FIP 2.15
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
