Parts List
Phaser 3610, WorkCentre 3615 Service Manual5-62
Quick Reference Spares List for the 3610 and 3615
SFP/MFP Part Number Part Description PL Number REP Number
SFP
MFP
604K85880
604K85890
Front Cover Assembly
Front Cover Assembly
PL 1.1
PL 1.2
REP 1.2
SFP
MFP
848E82792
848E82815
Left Side Cover
Left Side Cover
PL 1.1
PL 1.2
REP 1.7
REP 1.11
SFP
MFP
604K84920
604K84931
Top Front Cover Assembly
Top Front Cover Assembly
PL 1.1
PL 1.2
REP 1.3
SFP
MFP
604K84941
848K68342
Right Side Cover
Right Side Cover
PL 1.1
PL 1.2
REP 1.6
REP 1.13
SFP
MFP
848K62885
848K62912
Top Cover Assembly
Top Cover Assembly
PL 1.1
PL 1.2
REP 1.4
REP 1.15
SFP
MFP
848K70060
604K85650
Rear Cover Assembly
Rear Cover Assembly
PL 1.1
PL 1.2
REP 1.5
REP 1.18
SFP
MFP
848E82672 Lower Rear Cover PL 1.1
PL 1.2
REP 1.8
REP 1.18
MFP 848E82901 IIT Lower Right Cover PL1.2 REP 1.13
MFP 848E89270 IIT Right Inner Cover PL 1.2 REP 1.14
MFP 848E89213 Upper Left Side Cover PL 1.2 REP 1.16
MFP 848E89231 Upper Right Side Cover PL 1.2 REP 1.13
SFP
MFP
604K77391
604K85900
Cover Extension Assembly
Cover Extension Assembly
PL 1.1
PL 1.2
REP 1.3
868E76893 Rear Strap PL 1.3 NA
SFP 848K79123 Control Panel PL 1.4 REP 1.1
MFP 848K75635
848K82824
Control Panel 110V
Control Panel 220V
PL 1.5 REP 1.12
MFP 848E93191 IIT Front Bottom Cover PL 1.5 REP 1.10
MFP 848E93181 IIT Front Top Cover PL 1.5 REP 1.9
MFP 848E93171 Lower Left Side Cover PL 1.5 REP 1.17
059K79334 Registration Transport Assembly PL 2.1 REP 2.2
803E13351 Tray 1 Stopper PL 2.1 REP 2.8
