Xerox WorkCentre 3615 Service Manual

Wiring
Phaser 3610, WorkCentre 3615 Service Manual7-48
3. ROS
MCU PWB
PL 5.3
ESS PWB
PL 5.1 / 5.2
ROS Assembly
PL 3.2
Polygon Assembly Motor
Motor
Control
M
LDD PWB
ROS-MCU Harness
PL 3.2
Video Harness
PL 3.2
SOS
PWB
3
4
5
1
2
3
2
1
5
4
I/L+24VDC
RTN
N.C. N.C.
I/L +24VDC
P/J18
ROS MOT ON
ROS CLOCK
3
4
5
1
2
3
2
1
5
4
DATA+1
DATA-1
DATA+2
SG
DATA-2
P/J322
3
4
5
1
2
6
5
4
8
7
RTN
LD +5VDC
LD +5VDC
P/J19 P/J501
P/J502
1
2
3
3
2
1
SG
SOS SNR
SOS SNR
VREF
PCONT 1
PCONT 2
6
7
8
3
2
1
MO2
LDENB
A
s3610-191
From
AC Power

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
