Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-275
FIP 1. 290
091-914 IOT Drum Communication Fail
091-915 Drum CRUM Data Broken Fail
091-921 IOT Drum Detached
091-963 IOT Drum CRUM ID Error
Cause:
091-914: Communication failure with Drum CRUM was detected.
091-915: Malfunction of Drum CRUM was detected.
091-921: It was detected that the Drum CRUM is not at the specified position.(Loose CRUM)
091-963: The Drum CRUM ID error was detected.
8
•Replace (REP 7.5 Optional Tray PWB Assembly)
• Does an error occur?
Go to Step 9.
Troubleshooting
complete.
9
•Replace (REP 7.8 Feeder Assembly).
• Does an error occur?
Replace
(REP 5.6
MCU PWB)
Troubleshooting
complete.
Step Check and Action Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
