Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-320
FIP 2.07
Path Sensor
Cause:
Parts to be considered:
• PRE REGI-ACTUATOR (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder (4/4))
•PATH SENSOR (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder (4/4))
• OPTIONAL REGI HARNESS ASSEMBLY (PL 7.4 Tray 1/Optional Tray 550-Sheet Feeder
(4/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the PATH
SENSOR DETECTOR?
Remove the foreign
substances
Go to Step 2.
2
Is the PRE REGI-ACTUATOR damaged?
Replace the PRE
REGI-ACTUATOR
Go to Step 3.
3
Check the connection between the Path
Sensor & the OPTIONAL TRAY PWB ASSY.
• Is the OPTIONAL REGI HARNESS
ASSEMBLY (P/J4212 - P/J4214)
connected securely?
Go to Step 4.
Securely con-
nect the
Optional Regi
Harness
Assembly
4
• Replace the Path Sensor.
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
• Replace the OPTIONAL REGI HARNESS
ASSEMBLY.
Does an error occur? Replace the MCU
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
