Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-325
FIP 2.12
Optional Feeder Clutch Assembly
Cause:
Parts to be considered:
• OPTIONAL FEEDER GEAR 550 (PL 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4))
•FEED CLUTCH ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• C2 TURN HARNESS ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
• OPTIONAL TRAY PWB ASSEMBLY (PL 7.1 Tray 1/Optional Tray 550-Sheet Feeder (1/4))
Solution:
Step Check and Action Yes No
1
Are there any foreign substances in the FEED
CLUTCH ASSEMBLY Drive Section?
Remove the for-
eign substances
Go to Step 2.
2
Is the OPTIONAL FEEDER GEAR 550 dam-
aged?
Replace the
OPTIONAL
FEEDER GEAR 550
Go to Step 3.
3
Check the connection between the FEED
CLUTCH ASSEMBLY and the OPTIONAL TRAY
PWB ASSEMBLY.
• Is the C2 TURN HARNESS ASSEMBLY
(P/J4201P/J420) connected securely?
Go to Step 4.
Securely con-
nect the C2
TURN HARNESS
ASSEMBLY
4
•Replace (REP 7.7 Feed Clutch Assembly).
Does an error occur? Go to Step 5.
Troubleshooting
complete.
5
• Replace the C2 TURN HARNESS
ASSEMBLY
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
