Wiring
Phaser 3610, WorkCentre 3615 Service Manual 7-51
6. Controller (3610)
1
2
3
12
11
10
LINE SYNC
PAGE SYNC
TEST PRINT
SG
SG
SG
SG
4
5
9
8
6
7
8
7
6
5
CMD READY
COMMAND
9
10
4
3
STATUS
1
2
3
8
7
6
PS 3.3V
BUT 5V
TXD
PS LED
PS SW
SG
4
5
5
4
6
7
8
3
2
1
RXD
BUT 3.3V
11
12
2
1
RDY PWR ON
IOT PWR STS
1
2
1
2
STBY +5VDC
STBY +5VDC
RTN
MCU PWB
PL 5.3
B
To
AC Power
E
From
AC Power
ESS PWB
PL 5.1
ESS Harness
PL 5.4
SFP Console Harness
PL 1.1
SFP Console
Assembly
PL 1.1
P/J220P/J331
P/J321P/J20
P/J211 P/J341
LVPS
PL 5.1
Memory Kit (Option)
PL5.1
Wireless Adapter
(Option)
PL5.1
SD-Card (Option)
PL 5.1
P/J301
P/J314
P/J311
P/J312
P/J361
P/J362 N.C.
N.C.
P/J305
Ethernet Port
USB Port
s3610-194
