Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-259
FIP 1. 273
071-100 IOT Tray1 Misfeed Jam
050-134 is displayed in the UI.
Cause:
After the Tray 1 Feed Clutch turned ON, the Regi. Sensor did not turn ON within the specified
time.
Solution:
1. Paper jam has occurred. Remove the jammed paper.
2. If there is no jammed paper, or the error still occurs after having removed the jammed paper,
turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
Is there any foreign substances or bits of paper
found on the paper transport path?
Remove the for-
eign substances
and bits of paper,
etc.
Go to Step 2.
2
Are the paper feed rolls installed properly? Go to Step 3.
Reinstall the
corresponding
paper feed
rolls
3
Are the paper feed rolls deformed or worn out?
Replace the corre-
sponding paper
feed rolls
Go to Step 4.
4
• Execute the Diag Digital Input [071-102] to
check the operation of the Regi. Sensor HVPS.
• Is the Regi. Sensor HVPS operating normally?
Go to Step 5.
Go to
FIP 2.03
5
• Execute the Diag Digital Output [071-005] to
check the operation of the CST FEED
CLUTCH.
• Is the CST FEED CLUTCH operating properly?
Go to Step 6.
Go to
FIP 2.11
6
• Execute the Diag Digital Output [071-001] to
check the rotation of the MAIN DRIVE
ASSEMBLY.
• Is it working properly?
Replace
(REP 5.6 MCU
PWB)
Go to
FIP 2.15

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
