Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-266
FIP 1. 280
073-211 Feeder 3 Error
074-211 Feeder 4 Error
Cause:
073-211: IOT Option Feeder3 Failure.
074-211: IOT Option Feeder4 Failure.
Solution:
Turn the power Off and On to check that the error recurs, then proceed to the FIP.
Step Check and Action Yes No
1
Check the operation of the
OPTIONAL TRAY MOTOR
ASSEMBLY
• Execute the Diag Digital Output Tray 3:071-
012 / Tray 4:071-015 to check the rotation of
the OPTIONAL TRAY MOTOR ASSEMBLY.
• Is it working properly?
Go to Step 2.
Go to
FIP 2.17
2
Check the connection between the OPTIONAL TRAY
PWB ASSEMBLY (Upper) and the OPTIONAL TRAY
PWB ASSEMBLY (Lower).
• Are the FEEDER HARNESS ASSEMBLY DRAWER
2 (P/J423P/J4231) and the FEEDER HARNESS
ASSEMBLY DRAWER 1 (P/J4231P/J419)
connected securely?
Go to Step 3.
Securely connect
the
FEEDER HAR-
NESS ASSEMBLY
DRAWER 2 and
the
FEEDER HAR-
NESS ASSEMBLY
DRAWER 1
3
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 2.
• Does an error occur?
Go to Step 4.
Troubleshooting
complete.
4
• Replace the FEEDER HARNESS ASSEMBLY
DRAWER 1.
• Does an error occur?
Go to Step 5.
Troubleshooting
complete.
5
•Replace(REP 7.5 Optional Tray PWB Assembly)
• Does an error occur?
Go to Step 6.
Troubleshooting
complete.
6
•Replace (REP 7.8 Feeder Assembly).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
