Wiring
Phaser 3610, WorkCentre 3615 Service Manual 7-5
233 Illustration 10 Connects FUSING UNIT and FUSER HARNESS ASSY
240 Illustration 07 Connects LVPS PWB and REAR FAN HARNESS ASSY
241 Illustration 07 Connects LVPS PWB and LVPS FAN
250 Illustration 07 Connects LVPS PWB and TEST RELAY HARNESS ASSY
251 Illustration 07 HARNESS ASSY TEST RLY Test Port
253 Illustration 11
Connects CRUM TONER CONNECTOR ASSY and XERO CRUM
HARNESS ASSY
254 Illustration 11
Connects CONNECTOR ASSY XERO and XERO CRUM HARNESS
ASSY
261 Illustration 08 Connects HVPS and HVPS HARNESS ASSY
271 Illustration 10 Connects EXIT SENSOR and EXIT HARNESS ASSY
402 Illustration 07 Connects ESS PWB and FAX PWB ASSY
411 Illustration 07 ESS PWB to USB Port
412 Illustration 07 Connects ESS PWB and WIRELESS ADAPTER
414 Illustration 07 ESS PWB Ethernet Port
415 Illustration 07 Connects ESS PWB and FRONT USB ASSY
416 Illustration 07 Connects ESS PWB and UI HARNESS ASSY
421 Illustration 07 Connects ESS PWB and ESS HARNESS ASSY
422 Illustration 07 Connects ESS PWB and VIDEO HARNESS
432 Illustration 07 Connects ESS PWB and SPEAKER ASSY
441 Illustration 07 Connects ESS PWB and ESS HARNESS ASSY
451 Illustration 07 Connects ESS PWB and IIT ASSY
452 Illustration 07 Connects ESS PWB and IIT ASSY
453 Illustration 07 Connects ESS PWB and DADF ASSY
454 Illustration 07 Connects ESS PWB and IIT ASSY
462 Illustration 07 ESS PWB (not used)
501 Illustration 09 Connects ROS ASSY and ROS-MCU HARNESS
502 Illustration 09 Connects ROS ASSY and VIDEO HARNESS
2401 Illustration 10 Connects Rear Fan and REAR FAN HARNESS ASSY
CON 12 Illustration 12 Connects the Length Sensor to the DADF PWB
P/J (3615) Illustration Description
