Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-45
005-121
Paper Jam 005-121
Open the Document Feeder
Cover and remove paper.
(After jam recovery)
Reload the original that was
removed from the Document
Feeder and press the Start but-
ton.
N Scanned
<DADF JAM>
Cause:
Detect DADF JAM.
FIP 1. 02
005-124
Document Feeder Jam 005-124
Job Canceled.
Open Document Feeder Cover
and Remove Jammed Paper.
<Virtual JAM>
Cause:
Detect Virtual JAM.
FIP 1. 02
005-301
Document Feeder Cover Open
005-301
Close Document Feeder Cover.
<DADF Cover Open>
Cause:
Detect DADF Cover Open.
FIP 1. 03
005-900
Paper Jam 005-900
Open the Document Feeder
Cover and remove paper.
(After jam recovery)
Reload the original that was
removed from the Document
Feeder and press the Start but-
ton.
N Scanned.
<DADF STATIC JAM>
Cause:
Detect DADF STATIC JAM.
FIP 1. 02
010-317
Fuser Connection Error 010-
317
Turn off the printer and reseat
the Fuser.
<FUSING ASSEMBLY Detached>
Cause:
FUSING ASSEMBLY detached is
detected.
FIP 1. 04
010-397
Fuser Error 010-397
Power Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
Code:xxxxxxxxh
<FUSING ASSEMBLY Failure>
Cause:
The operation error of FUSING
ASSEMBLY
(Temperature anomaly error etc.) is
detected.
FIP 1. 04
Status
Code
(3615)
LCD Display Name/Description of Error FIP

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
