Xerox WorkCentre 3615 Service Manual

Overview
Phaser 3610, WorkCentre 3615 Service Manual 1-7
Servicing Electrical Components
Before starting any service procedure, switch the printer power Off and unplug the power cord from the
wall outlet. If you must service the printer with power applied, be aware of the potential for electrical
shock.
WARNING: Do not touch any electrical component unless you are instructed to do so by a service
procedure.
Servicing Mechanical Components
When servicing mechanical components within the printer, manually rotate the Drive Assemblies,
Rollers, and Gears.
WARNING: Do not try to manually rotate or manually stop the drive assemblies while any printer
motor is running.
Servicing Fuser Components
WARNING: This printer uses heat to fuse the toner image to paper. The Fuser is VERY HOT. Turn
the printer power Off and wait at least 5 minutes for the Fuser to cool before attempting to service
the Fuser or adjacent components.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
