Xerox WorkCentre 3615 Service Manual

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-26
7
Adjust the voltage value of the Transfer Roller
Assembly by performing the Adjust Transfer Unit
(ADJ 2 Adjusting the Transfer Unit)
Is the image printed correctly?
Troubleshooting
complete.
Go to step 8.
8
Reseat the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 9.
9
Remove (REP 3.4 Transfer Roller Assembly).
Are the Plate Spring BTR on the HVPS dirty or
deformed?
Clean up the Plate
Spring BTR or replace
(REP 5.7 HVPS (3610) /
REP 5.8 HVPS (3615)),
then go to step 10.
Go to step 10.
10
Reseat (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 3.4
Transfer Roller
Assembly).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
