Xerox WorkCentre 3615 Service Manual

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-36
6
Is the Drum Cartridge installed properly, with no
foreign substances at the contact point between
the ATC Sensor in the Drum Cartridge and the
Xerographic Connector Assembly?
Go to Step 7.
Reinstall the Drum Car-
tridge, then go to
step 7.
7 Is the connection terminal of the ATC Sensor part
in the Drum Cartridge damaged?
Replace the Drum Car-
tridge, then go to
step 8.
Go to Step 8.
8
Is the connection terminal of the Xerographic
Connector Assembly damaged?
Replace (REP 3.3
Xerographic Connector
Assembly), then go to
step 9.
Go to Step 9.
9 Is the image printed correctly?
Troubleshooting
complete.
Replace the Drum Car-
tridge.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
